The core part of magnetic stirring is a ring-shaped strong magnetic coupling stirring device. Multiple magnetic steel rings are made of two powerful permanent magnets inside and outside; the inner magnetic steel body is enclosed in a stainless steel sealed cylinder connected to the stirring part, sealing the cylinder and the kettle The cover, the kettle body, and the fastening connection form a static sealed cavity, so that the reaction medium is completely in a static sealed state, without any leakage, pollution or personal danger; the speed-regulating motor drives the outer magnetic steel body, and the strong magnetic force passes through the stainless steel without contact The resultant sealed cylinder attracts each other with the strong magnetic force of the inner magnetic steel body enclosed in the sealed cylinder, mutually positions itself and acts on the axial rotation traction to perform high temperature and high pressure stirring reaction.

The catalytic hydrogenation reactor is equipped with an explosion-proof motor and an explosion-proof control cabinet, and is well sealed, suitable for various chemical production reactions of catalytic hydrogenation.

Hydrogenation reaction refers to a reaction process in which hydrogen interacts with other compounds, usually in the presence of a catalyst. The hydrogenation reaction belongs to the category of reduction.

There are two types of commonly used hydrogenation reactors and reactors: one type is used for liquid phase hydrogenation process of high boiling point liquid or solid (solids need to be dissolved in solvent or heated and melted) raw materials, such as fat hydrogenation, heavy oil Hydrocracking, etc. Liquid phase hydrogenation is usually carried out under pressure, and the process can be batchwise or continuous. Intermittent liquid phase hydrogenation often uses an autoclave or bubbling reactor with a stirring device. The continuous liquid-phase hydrogenation can adopt a trickle bed reactor or a tubular reactor with three-phase continuous flow of gas, liquid and solid. Another type of reactor is used for continuous gas-phase hydrogenation processes, such as atmospheric gas-phase hydrogenation of benzene to cyclohexane, high-pressure gas-phase hydrogenation of carbon monoxide to synthesize methanol, etc. The reactor type can be tubular or tower. In the food field, it is mainly used to produce sorbitol, xylitol, maltitol and other continuous hydrogenation reactions, as well as intermittent hydrogenation reactions.

The stirring form of batch hydrogenation reactor is generally three-layer combined stirring, including paddle stirring, self-priming stirring and disc turbine dispersion stirring, which can also be selected according to user requirements. Our self-priming stirring paddle adds a set of riders, which can make the gas enter the hollow shaft of the stirring paddle more smoothly, and fully mix with the liquid gas.

Zhengwei hydrogenation reactor is equipped with CT4 explosion-proof motor and explosion-proof control box. All electrical components are explosion-proof configuration, so that customers can use it safely.

Heat transfer oil is a kind of heat carrier oil, a kind of special oil with good thermal stability for indirect heat transfer. Because of its uniform heating, accurate temperature control, high temperature under low vapor pressure, good heat transfer effect, energy saving, convenient transportation and operation, etc., it has been widely used in various occasions in recent years, and its use and dosage are more and more More and more. The Zhengwei reactor is equipped with an electric heating rod in the heating jacket and uses electric heating oil to achieve a stable temperature rise in the oil bath of the kettle body without the need for an additional external circulation device. For larger reactors, a hot oil pump is additionally equipped to circulate the heat transfer oil in the jacket to prevent coking.

The medium in the reaction kettle contains hydrogen, so it is equipped with explosion-proof motors and explosion-proof electrical components to improve the safety performance of the equipment.
